Supermicro SuperStorage 6029P-E1CR24H 2U Rackmount Server


Corporate Database
Database Processing & Storage
Enterprise Server
HPC, Data Center
  • 2U Rackmount Server
  • Dual Socket P (LGA 3647) Supports Intel® Xeon® Scalable Processors, 3 UPI up to 10.4GT/s
  • Intel® C621 Chipset
  • Up to 3TB ECC 3DS LRDIMM, up to DDR4-2666MHz; 24 DIMM Slots
  • 24x Hot-swap 3.5" SAS3/SATA3 Drive Bays
    2x Rear Hot-swap 2.5" SATA Drive Bays
  • SAS3 (12Gbps) via Broadcom 3108; HW RAID, RAID 0, 1, 5, 6, 10, 50, 60
  • 2x PCI-E 3.0 x16, 1x PCI-E 3.0 x8 Slots
    1x SIOM Card Support (Flexible Networking) Note: Must Bundle with Network Card
  • Server Remote Management: IPMI 2.0 / KVM over LAN / Media over LAN
  • 5x Hot-swap 80mm High Performance PWM Fans
  • 1000W Redundant Power Supply, Titanium Level (96%)
  • 34" Depth Rack Mount Chassis

The Supermicro SuperStorage Server 6029P-E1CR24H is a 34" depth 2U Rackmount server that features 24x 3.5" Hot-swap SAS3/SATA3 drive bays w/ SAS3 RAID controller for high-capacity storage. Supports dual Intel® Xeon® Scalable Processor, up to 3.0TB Memory. The Supermicro Server 6029P-E1CR24H comes with five 80mm high performance PWM fans, is equipped with 1000W redundant titanium level power supply.

Due to the complexity of integration, this product is sold as completely assembled systems only. Please contact our Supermicro sales rep for special requirements.

Lowest Price Guaranteed on Complete Systems. Please Ask Sales for Details.

Barebone & Base Configurations

2U Supermicro Rack Mount Server With X11DSC+ Motherboard

  • Supermicro X11DSC+ Motherboard
  • 2x Six-core Intel® Xeon® Bronze 3204 Processor (8.25M Cache, 1.90 GHz)
  • 32GB(4x 8GB) DDR4 ECC Registered Memory
  • 12x 1.0TB SATA3 6.0Gb/s 7200RPM 3.5" Enterprise Hard Drive
  • 24x 3.5" Hot-swap SAS3/SATA3 Drive Bays, 2x Rear Hot-swap 2.5" Drive Bays
  • Broadcom 3108 SAS3 RAID Controller
  • 1 x Supermicro SIOM 1-Gigabit Ethernet Adapter AOC-MGP-i2 (2x RJ45)
  • Built-in Video
  • 1000W Redundant Power Supply, Titanium Level Certified

Barebone Only:
