eBOX630-528-FL Fanless Embedded PC with 8th Gen Intel® Core™ i7/i5/i3 & Celeron® ULT Processor

Features:

  • 8th Gen Intel® Core™ i7/i5/i3 & Celeron® ULT Processor (Whiskey Lake-U)
  • 2x 260-pin DDR4 SO-DIMM (Max. 64GB)
  • Supports 2 HDMI, VGA, 3 GbE LAN, 4 COM and 6 USB
  • Trusted Platform Module (TPM 2.0 Onboard)
  • Fanless -40°F to +158°F Operating Temperature
  • 9 to 36 VDC Wide Range DC Power Input
  • AMS.AXView Intelligent Remote Monitoring Software Supported


The eBOX630-528-FL is a new entry to the Fanless Embedded line of products. The embedded system is constructed with an extruded aluminum and heavy-duty steel exterior with a hardness rating of IP40. The motherboard is installed with options ranging from i3, i5, and i7 intel 8th generation processors. Additionally the Celeron 4305UE is also supported and all processors utilize the SoC integrated chipset. The two memory modules included can utilize DDR4-2400 SO-DIMM RAM, which in turn supports a maximum capacity of up to 64GB. In terms of power, the unit can run with a voltage range of 9V to 36V with a power adapter. The operating temperature can range from –40C to 70C. The embedded system also comes installed with an embedded operating system using either Linux or Windows 10 IoT. Expansion options are also available as there are 2 Full-sized PCIe mini card slots for the user to freely customize.

Barebone & Base Configurations

eBOX630-528-FL Fanless Embedded PC

  • Intel® Celeron® Processor 4305UE (2M Cache, 2.00 GHz
  • Up to Intel® Core™ i7 Processor (Optional)
  • 4GB DDR4 SO-DIMM Memory
  • 250GB 2.5" SATA Solid State Drive
  • 2x 2.5" Hot Swappable HDD Drive Bay
  • 2x RS-232 (DB-9), 2x RS-232/422/485 (DB-9)
  • 2x USB 3.2 Gen2, 2x USB 3.2 Gen1, 2x USB 2.0
  • 1x mSATA
  • 2x HDMI (Lockable), 1x VGA
  • TPM 2.0
  • 8-CH TTL DIO via DB9 Female
  • 2x Full-size PCIe Mini Card Slots
  • 3x GbE LAN
  • 9-36 VDC Terminal Block Power Connector
    120W 24V Power Adapter (Optional)

Barebone Only:

$759.00

Configured:

$855.00

Customize
