Ebox630B Fanless Embedded System with Core Ultra Processor
Features:
- Intel Core Ultra processor (Meteor Lake-H)
- Multiple compute engines : CPU, GPU (Intel Arc GPU by H SKU) and NPU (Intel AI Boost)
- 2 x DDR5 SO-DIMM Memory (Max. 96GB)
- 2 x 2.5" Swappable SSD/HDD Drive Bays with RAID 0 & 1 Supported
- 1 x M.2 2280 M key Socket (PCIe x4) for NVMe SSD
- Supports Multiple Display Interfaces with 1 HDMI 1.4b and 3 x DisplayPort (2 Ports via USB Type-C)
- Supports 3 x 2.5 GbE LAN with TSN, 1 x GbE LAN, 6 x USB, 4 x COM
- TPM 2.0 Onboard
- -40°F to 140°F Wide Range Operation Temperature
- Wide Range Power Input From 9 to 60 VDC
- Supports the OpenVINO toolkit for AI computing
Barebone & Base Configurations
eBOX630B Fanless Embedded PC
- Intel Core Ultra 5 Processor 125H (18M Cache, up to 4.50 GHz)
Intel Core Ultra 7 Processor 155H (24M Cache, up to 4.80 GHz) (Optional) - 8GB DDR5 SO-DIMM Memory
- 500GB M.2 Solid State Drive
- 2 x RS-232 (DB-9), 2 x RS-232/422/485 (DB-9)
- 4 x USB 3.2, 2 x USB 2.0, 2 x USB Type-C
- 1 x HDMI 1.4b (Lockable), 1 x DisplayPort 1.4a
- 1 x 8-CH TTL DIO (DB9 Female Connector, 4 in/4 out)
- TPM 2.0 Onboard
- 3 x 2.5GbE LAN, 1 x GbE LAN
- 1 x Full-size PCI Express Mini Card (USB + PCIe Signal)
- 1 x M.2 Key E 2230 (for Wi-Fi)
- 9-60 VDC Terminal Block Power Connector
120W 24V Power Adapter (Optional)
Configured: |
$1,539.00 |
