GOT317B-ADL-TRD 17" Fanless Panel PC
Features:
- 17" SXGA LCD with 5-wire Resistive Touch Screen
- 14th/13th/12th gen Intel Core i9/i7/i5/i3 or Pentium Processor (up to 35W)
- Intel H610 Chipset
- 1 x 260-pin DDR4 3200 SO-DIMM (Max. 32GB)
- 1 x 2.5" SATA HDD w/ Swappable HDD Tray
- TPM 2.0 Onboard
- Supports 4 x USB and 2 x COM Ports
- 1 x Flexible I/O window, Supporting COM3, COM4, and DIO (On-board Optional)
- Supports WLAN Module and Antenna (optional)
- Supports Panel Mount, Wall Mount, VESA Arm, and Desktop Stand
- Flat Front Panel Touch Screen with Rugged IP65 Front Bezel
The GOT317B-ADL-TRD is a durable 17" panel computer built for industrial environments, featuring an SXGA LCD with 350 nits of brightness and a 5-wire resistive touch screen for reliable input control. Its flat front panel and rugged IP65-rated front bezel provide protection against dust and water, making it ideal for harsh settings. The fanless design ensures silent operation and enhanced reliability, while the swappable HDD tray and support for one 2.5" SATA HDD/SSD offer convenient storage options. With TPM 2.0 onboard for secure computing, and optional WLAN module and antenna support, it also includes 4 USB and 2 COM ports for versatile connectivity. Mounting flexibility is ensured with support for panel, VESA, desktop stand, and wall installations.
Barebone & Base Configurations
- 17" 1280x1024 350 nits TFT LCD w/ 5-wire Resistive Touch Screen
- Intel Pentium Gold G7400T Processor (6M Cache, 3.10 GHz)
- Up to 14th/13th/12th gen Intel Core i9/i7/i5/i3 or Pentium processor
- 8GB DDR4 SO-DIMM Memory
- 480GB 2.5" SATA Hard Drive
- 1 x RS-232/422/485 (DB9), 1 x RS-232 (via Cable
- 2 x USB 3.2, 2 x USB 2.0 Ports
- 2 x HDMI
- TPM 2.0
- 1 x PCI Express Mini Card (USB+PCIe signal+nano SIM slot “LTE”)
- 1 x M.2 Key E 2230 with PCIe x1 and USB 2.0
- 1 x 2.5GbE LAN, 1 x GbE LAN
- 10 ~36VDC Terminal Block Power Connector
