GOT710S-837 10.4" Railway Fanless Touchscreen Panel PC
Features:
- Sunlight Readable 10.4" SVGA, 1000 nits High Brightness
- Intel® Atom™ E3845 1.91 GHZ Processor
- Default 4GB DDR3 Memory Onboard , 8GB (Optional)
- Alternative Keypad Control in Front Bezel
- All Lockable Connectors Design
- Fanless System with Wide Operating Temperature Range of -13°F - +158°F
- EN50155 Certificated for Railway Application
- Typical 24 to 110VDC Power Input, EN 50155 Class S3
- 20ms Power Interruption Protection
The GOT710S-837 is a Fan-less Touch Panel PC with a 10.4" TFT LCD and a 5-wire resistive touch screen. The aluminum front bezel is rated at IP65, with a rear bezel of IP40. This GOT supports Intel’s Atom processor E3845 1.91 GHz and 4GB DDR3L onboard memory. 16GB flash onboard and one mSATA offers two options for storage. For Expansion options there are two PCI Express Mini Card slots. The GOT710S-837 has two RS-232/422/485 with isolated 1.5KV (D-sub 9 male), and one USB 2.0 port. A wide range of power input is supported ranging from 24 to110 VDC. The GOT710S-837 can operate in temperatures ranging from -13°F to +158°F and measures 12.20" x 2.42" x 8.43".
Base Configurations
- 10.4" 800x600 1000 nits TFT LCD w/Touch Screen
- Intel® Atom™ E3845 1.91 GHZ Processor
- 4GB DDR3L Memory Onboard
- 16 GB Flash Onboard
- 2 x Gigabit Ethernet LAN (M12)
- 2 x USB2.0 (M12)
- 2 x RS-232/422/485 (M12)
- Fanless Touch Panel PC
- 1 x DIO (6 Input/2 Output) with Isolated 1.5KV (Phoenix Type)
- 1 x CAN Bus with Isolated 1.5KV (D-sub)
- DC for Power Input with Isolated 1.5KV
Configured: |
$2,795.00 |
