IPC920 Industrial Embedded PC with 12th/13th/14th Gen Intel Core i7/i5/i3 or Celeron Processor
Features:
- 12th/13th/14th Gen Intel Core i7/i5/i3 / Celeron Processor
- Intel H610E/R680E Chipset
- 2 x DDR5 SO-DIMM (Max. 96GB)
- 2 x 2.5" HDD/SSD bay (7/9.5 mm Height); Supporting RAID 0, 1 (R680E)
- 1 x M.2 Key M 2280 Socket (PCIe x4 Gen4)
- Easy Expansion via Flexible I/O Window
- Intelligent Power Management: Ignition, USB Power On/Off Control
- Supports Connectors with Pull-resistance Design
- EN 61000-6-2 Certified
- Optional DIN-rail, Bookshelf and Wall Mount Kit
Barebone & Base Configurations
IPC920 Industrial Embedded PC
- Intel Celeron Processor G6900T (4M Cache, 2.80 GHz)
- 8GB DDR5 SO-DIMM Memory
- 500GB M.2 NVME Solid State Drive
- 2 x RS-232/422/485 (DB-9)
- 4 x USB 3.2, 1 x USB 2.0 180D Type-A (Internal, up to 30 mm)
- TPM2.0
- 1 x PCIe x16 Expansion Slot (Optional)
- 1 x HDMI, 1 x DisplayPort
- Built-in 2 x 2.5GbE LAN, 1 x GbE LAN
- 18~36 VDC Power Input
- 120W Wire Power Adapter (Optional)
230W Wire Power Adapter (Optional)
Configured: |
$1,495.00 |
