PPC2-C17-ADL 17" Heavy Industrial Panel PC
Features:
- 17” 1280 x 1024 350 nits TFT LCD with Projected Capacitive Touch Screen
- 12th Gen Intel® Core™ i9/i7/i5/i3 and Pentium® Processor
- Intel® H610 Chipset
- 2 x 260-pin 3200 MHz Dual-Channel DDR4 SO-DIMM (MAX, 64GB)
- 1 x 2.5'' SATA HDD/SSD Drive Bay
- 1 x M.2 M Key 2242/2280 NVMe (PCIe Gen3 x 4), 1 x M.2 E-Key 2230 (PCIe Gen3 x1 + CNVIo + USB 2.0)
- 1 x PCIe Gen4 x16 Slot (x16 Signal)
- 4 x USB 3.2, 2 x USB 2.0
- 2 x 2.5GbE LAN Ports
- Anti-glare and Anti-UV PCAP
- Support Gloved and Wet Hand Operation
- Newly Designed Panel Mount Kit
- New Graphical BIOS Interface
The PPC2-C17-ADL heavy industrial panel PC is a formidable computing solution designed to excel in demanding industrial environments. Powered by the 12th Gen Intel® Processors Platform, it offers exceptional processing power and efficiency. With a PCIe Gen4 x16 slot (x16 signal), it provides extensive expansion options for various peripherals and add-ons. Its anti-glare and anti-UV PCAP touchscreen ensures optimal visibility and durability, even in harsh conditions, while also supporting gloved and wet hand operation for user convenience. The newly designed panel mount kit enhances installation versatility, and the new graphical BIOS interface simplifies system management and configuration. The PPC2-C17-ADL is a robust choice for industrial applications requiring high performance, durability, and flexibility.
Barebone & Base Configurations
- 17” 1280 x 1024 350 nits TFT LCD Display with Projected Capacitive Touch Screen
- Intel Pentium Gold G7350 Processor (6M Cache 3.70 GHz)
- 8GB DDR4 SO-DIMM Memory
- 250GB M.2 Solid State Drive
- 1 x RS-232/422/485, 4 x RS-232
- 4 x USB 3.2, 2 x USB 2.0
- 1 x PCIe 4.0 x16 Slot
- 1 x M.2 E-Key 2230 (PCIe Gen3 x1 + CNVIo + USB 2.0)
- 1 x HDMI 2.0
- TPM
- 2 x 2.5 GbE LAN
- 250W AC input ATX Power Supply
