Features:

• Intel N150 Processor
• 1 x DDR5 SO-DIMM (Max. 16GB)
• 1 x 2280 M.2 M-Key (PCIe Gen 3x1, SATA 6Gb/s)
• 1 x 2230 M.2 E-Key (WiFi/BT)
• 1 x 3042 M.2 B-key with SIM Slot (Support 3G/4G LTE Module)
• 3 x HDMI for Multiple Display (2 Ports support CEC)
• Support Micro SD Card
• 2 x GbE LAN Port
• Support COM (RS-232 mode, pass through RJ45 port)

The QS-N150A is an ultra-slim, fanless industrial embedded system powered by the Intel Processor N150, delivering reliable, energy-efficient performance for digital signage, edge computing, and embedded applications. With a compact 165 × 105 × 27 mm form factor, it supports single-channel DDR5 memory through one SO-DIMM slot and features three HDMI outputs for multi-display installations, with two ports supporting CEC for enhanced display control. The system also includes dual Gigabit Ethernet ports, Micro SD card support for expandable storage, and an RS-232 COM interface via an RJ45 pass-through port, providing the connectivity and flexibility required for a wide range of industrial deployments..
