RMS242-AMD 2U Industrial Rack Mount Computer


  • 2U Rack Mount Industrial Computer
  • Flexible Front I/O Options
  • Heavy-duty Preplated SPGC Cold-rolled Steel
  • EATX/ATX Motherboard (up to 12" x 13")
  • 4 x 2.5" Hot-swap Drive Bays
  • 1 x PCIe 3.0 x16 Slot, 1 x PCIe 4.0 x8 Slot
  • Front Access: 2 x USB 3.0
  • 4 x 60x38mm Easy Swap Cooling Fans
  • 800W Redundant 80+ Platinum Power Supply
  • 17.7" Short-depth Rack Mount PC

The RMS242 computer chassis is a versatile and high-performance solution that caters to the needs of systems centered on AMD components. It offers flexible front and rear I/O application options, allowing for customized configurations. With four easy-swap fans, it ensures superior cooling for your components, enhancing system reliability. The chassis supports GPU cards with a 2U riser card, making it suitable for graphics-intensive applications. It also accommodates up to four 2.5" external hot-swap drive bays, providing ample storage capacity. Equipped with a redundant PSU with 80+ Platinum efficiency, it ensures power stability. The inclusion of two front-access USB 3.0 ports adds convenience, while its short-depth design is perfect for space-critical deployments. Whether you require 2 post or 4 post rack deployment, the RMS242 offers the flexibility and performance needed for your computing infrastructure.

Need a Custom Solution Not Offered Online? Click the Button Below.

Base Configurations

2U Rackmount Computer with Supermicro H13SSL-N Motherboard

  • Supermicro H13SSL-N Motherboard
  • 4th Generation AMD EPYC™ Processors
  • 16GB DDR5 ECC Registered Memory
  • 500GB M.2 NVME Solid State Drive
  • 2 x M.2 Slots
  • 3 x PCIe 5.0 x16, 2 x PCIe 5.0 x8
  • 2 x GbE LAN, 1 x IPMI LAN
    2 x 10GBase-T LAN (H13SSL-NT, Optional)
  • TPM Module (Optional)
  • 800W Redundant Power Supply




2U Rackmount Computer with Gigabyte MZ73-LM1 Motherboard

  • Gigabyte MZ73-LM1 Motherboard
  • 2 x 4th Generation AMD EPYC™ Processors
  • 32GB DDR5 ECC Registered Memory
  • 500GB M.2 NVME Solid State Drive
  • 1 x TPM Header
  • Built-in Video
  • Built-in 2 x 10GBase-T LAN, 1 x IPMI LAN
  • 800W Redundant Power Supply
