RMS343-AMD 3U Rackmount Computer
Features:
- 3U rack mount industrial computer.
- 7 drive bays(4 x 5.25" and 3 x 3.5" Drive Bays).
- AMD ATX Motherboard.
- Dual Xeon processors support.
- 18.9" deep rack mount pc.
The RMS343-AMD series of rack mount industrial computer is a 3U high, designed for industrial control and server applications in harsh industrial environments. The RMS343-AMD rack mount industrial computer chassis is constructed of heavy-gauge steel for ruggedness and corrosion resistance. A lockable panel provides access to a front cooling fan, and a lockable, shielded door protects and affords easy access to the drives. Filtered ventilation fans prevent airborne dust particles from being drawn into the chassis.
This RMS343-AMD rack mount pc is ideal for high-density disk intensive web server, back office server, firewall, proxy server and VPN gateway applications including collocation.
Need a Custom Solution Not Offered Online? Click the Button Below.
Search Filter | Clear All |
Processor | Chipset | Memory | Expansion Slots | Features |
|
|
|
|
|
Base Configurations
3U Rackmount Computer with Supermicro H13SSL-N Motherboard
- Supermicro H13SSL-N Motherboard
- 4th Generation AMD EPYC™ Processors
- 16GB DDR5 ECC Registered Memory
- 250GB M.2 NVME Solid State Drive
- 24x SATA DVD+/-RW Optical Drive
- 2 x M.2 Slots
- 3 x PCIe 5.0 x16, 2 x PCIe 5.0 x8
- 2 x GbE LAN, 1 x IPMI LAN
2 x 10GBase-T LAN (H13SSL-NT, Optional) - TPM Module (Optional)
- 500W 2U ATX PFC 110/220 VAC Power Supply
3U Rackmount Computer with ASUS PRIME X670-P Motherboard
- ASUS PRIME X670-P ATX Motherboard
- AMD AM5 Socket for Ryzen Processors
- AMD X670 Chipset
- 8GB DDR5 Memory
- 250GB M.2 NVME Solid State Drive
- 24x SATA DVD+/-RW Optical Drive
- 3 x M.2 Slots
- 7 x USB3.2, 1 x USB3.2 Type C
- 1 x Thunderbolt Header
- 1 x TPM Header
- Built-in HDMI, DisplayPort and Audio
- Built-in 2.5GbE LAN
- 500W 2U ATX PFC 110/220 VAC Power Supply
3U Rackmount Computer with ASRock X670E PG Lightning Motherboard
- ASRock X670E PG Lightning ATX Motherboard
- AMD AM5 Socket for Ryzen Processors
- AMD X670 Chipset
- 8GB DDR5 Memory
- 250GB M.2 NVME Solid State Drive
- 24x SATA DVD+/-RW Optical Drive
- 4 x M.2 Slots
- 7 x USB3.2, 1 x USB3.2 Type C
- 1 x Thunderbolt Header
- 1 x TPM Header
- Built-in HDMI, DisplayPort and Audio
- Built-in 2.5GbE LAN
- 500W 2U ATX PFC 110/220 VAC Power Supply
3U Rackmount Computer with ASRock X570 Phantom Gaming 4 Motherboard
- ASRock X570 Phantom Gaming 4 ATX Motherboard
- AMD Ryzen 5 5500 6-core, 12-threads 3.60 GHz Processor
- AMD X570 Chipset
- 8GB DDR4 Memory
- 250GB M.2 NVME Solid State Drive
- 24x SATA DVD+/-RW Optical Drive
- 2 x M.2 Slots (2230/2242/2260/2280/22110), 1 x M.2 E Key for Wi-Fi
- 1 x Thunderbolt Header
- 1 x TPM Header, 1 x SPI TPM Header
- GeForce 210 1GB DDR3 64Bit PCI Express Video Card VGA/DVI/HDMI
- 8 x USB3.2 Ports
- Built-in Gigabit LAN
- 500W 2U ATX PFC 110/220 VAC Power Supply
3U Rackmount Computer with ASROCK ROMED8-2T/BCM Motherboard
- ASROCK ROMED8-2T/BCM Motherboard
- AMD EPYC™ 7003
- 16GB DDR4 ECC Registered Memory
- 250GB M.2 NVME Solid State Drive
- 24x SATA DVD+/-RW Optical Drive
- 2 x M.2 Slots
- 2 x 10 GbE LAN, 1 x IPMI LAN
- TPM Module (Optional)
- 500W 2U ATX PFC 110/220 VAC Power Supply
- Ships in 5 - 7 Business Days
3U Rackmount Computer with Supermicro H12SSL-C Motherboard
- Supermicro H12SSL-C Motherboard
- AMD EPYC™ 7003
- 32GB DDR4 ECC Registered Memory
- 250GB M.2 NVME Solid State Drive
- 24x SATA DVD+/-RW Optical Drive
- 2 x M.2 Slots
- 5 x PCIe 4.0 x16, 2 x PCIe 4.0 x8
- 2 x GbE LAN, 1 x IPMI LAN
- TPM Module (Optional)
- 500W 2U ATX PFC 110/220 VAC Power Supply
- Ships in 5 - 7 Business Days
