RMS413 4U Rackmount Computer
Features:
- 4U Rackmount Computer
- Support E-ATX Motherboard
- Support 7x Full-Size Expansion Card
- 3 x 5.25" External Drive Bays
- 1 x 3.5" External Drive Bay, 4 x 3.5" Internal Drive Bays
- Truly Isolated Anti-vibration Design on internal HDD and Drive Cages
- 1x 120mm Cooling Fan: Optional Second 3 x 5.25" Drive Cage for Maximum Configuration Flexibility, 84H342310-003
- 22.19" Depth Rackmount PC
The RMS413 is 4U rack mount server That supports Dual Xeon processors on a EATX motherboard. The chassis is equipped with shock insulated drive cages, dust-proof filter and add-on card retainer. It is the best industrial server solution for Surveillance DCR;GPU support server: Flash Array server; Video and Music Production; Network Telephony and Data Acquisitions.
The RMS413 comes with 3x5.25" external drive bays as standard; and 3 x 5.25" external drive bays can be filled with more removable kits to expand storage capacity.
Need a Custom Solution Not Offered Online? Click the Button Below.
Search Filter | Clear All |
Processor | Chipset | Memory | Expansion Slots | Features |
|
|
|
|
|
Base Configurations
- Supermicro X13SWA-TF Motherboard
- Intel Xeon W-2400 Processor, Intel Xeon W-3400 Processor
- Intel W790 Chipset
- DDR5 ECC Registered Memory
- M.2 NVME Solid State Drive
- 4 x PCIe 5.0 x4 M.2 Slots
- 6 x PCIe 5.0 x16
- 1 x TPM Header
- 2 x U.2 Connector
- Built-in 1x 10GbE LAN, 1x GbE LAN (Shared IPMI)
- Supermicro X13DAI-T Motherboard
- 2x 4th/5th Gen Intel Xeon Scalable processors
- Intel C741 Chipset
- DDR5 ECC Reg Memory
- M.2 NVME Solid State Drive
- 2 x PCIe 5.0 x4 M.2 Slots
- 4 x NVMe Ports PCIe 5.0 x4 via 2 MCIO Connectors
- 5 x PCIe 5.0 x16, 1 x PCIe 5.0 x8
- 1 x TPM Header
- Built-in 2 x 10G LAN
- Supermicro X13DEI Motherboard
- 2x 4th/5th Gen Intel Xeon Scalable processors
- Intel C741 Chipset
- DDR5 ECC Reg Memory
- M.2 NVME Solid State Drive
- 1 x TPM header
- Built-in 2 x Gigabit LAN & IPMI LAN
2 x 10GbE LAN (X13DEI-T, Optional)
- Supermicro X12SPA-TF Motherboard
- 3rd Gen Intel Xeon Scalable Processor
Intel Xeon W-3300 Processor - Intel C621A Chipset
- DDR4 ECC Registered Memory
- M.2 NVME Solid State Drive
- 4x PCI-E 4.0 x16, 3x PCI-E 4.0 x8 (in x16)
- 4x PCI-E 4.0 x4 M.2 Slots
- Built-in 2x 10GbE LAN, 1x GbE LAN, 1x IPMI LAN
- Gigabyte MD72-HB2 Motherboard
- 2x 3rd Gen Intel Xeon Scalable processors
- Intel C621A Chipset
- DDR4 ECC Reg Memory
- M.2 NVME Solid State Drive
- 1 x TPM Header
- 6 x PCIe 4.0 x16
- Built-in 2 x GbE LAN, 2 x 10GbE LAN, 1 x Management LAN
- Supermicro X11SPA-TF Motherboard
- Intel Xeon Bronze 3204 Processor (8.25M Cache, 1.90 GHz)
- Supermicro X11SPA-T Motherboard w/ Intel Xeon W-3200 Series Processor (Optional)
- Intel C621 Chipset
- DDR4 ECC Reg Memory
- M.2 NVME Solid State Drive
- 4 x M.2 Slots
- 4 x PCIe 3.0 x16, 3 x PCIe 3.0 x8 (in x16 Slot)
- Built-in Dual Gigabit LAN
- Ships in 5 - 7 Business Days
- Supermicro X11DPi-N Motherboard
- 2x Six-core Intel Xeon Bronze 3204 Processor (8.25M Cache, 1.90 GHz)
- Intel C621 Chipset
- DDR4 ECC Reg Memory
- M.2 NVME Solid State Drive
- Built-in Dual Gigabit LAN & IPMI LAN
- Ships in 5 - 7 Business Days
